ImpactSAFE Protection Post

Product Details

ImpactSAFE Protection Post: Medium duty post protection where space is limited

Pallet trucks and MHE operating in tight spaces create a constant risk of contact with vulnerable doors, exposed services and building projections. Each unaddressed impact increases the risk of personnel injury and structural damage to the building. This is a foreseeable risk. The ImpactSAFE Protection Post addresses these every day impacts directly.

The post sits at these common impact locations, providing a cost-effective, highly visible physical barrier between vehicles and the assets behind it. Its compact footprint provides meaningful protection without intruding into the operational space around it. Small in size, significant in impact.

Steel core, rubber buffer and rotating sleeve

The post centres on a 114mm diameter galvanised steel core with a 180mm x 180mm baseplate. A shock absorbing rubber buffer sits on top of the baseplate. It absorbs and arrests impact force before it reaches the core and the floor fixings. This protects the surrounding floor surface from damage under repeated contact. It also reduces the stress placed on the fixing anchors over time.

The steel core carries a hot dip galvanised finish to BS EN ISO 1461. A 123mm diameter rotating yellow polyethylene sleeve fits over the core and takes the direct impact of vehicle contact. The sleeve rotates on impact, distributing force more evenly and reducing concentrated damage at a single point. When the sleeve sustains significant wear it replaces independently. No repainting is required at any point.

Installation and fixing

The ImpactSAFE Protection Post is a bolt-down surface mounted system. Four M10 x 105mm Safety Plus Anchors secure each post to the floor, supplied as standard. The baseplate measures 180mm x 180mm and sits flush to the floor surface for a clean, stable installation. Everything needed is in the box.

Three height options are available: 600mm, 800mm and 1000mm. The 1000mm version is supplied as standard. The 600mm and 800mm options are available on request, subject to minimum order quantities.

Where the ImpactSAFE Protection Post is specified

The post suits warehouse doors, exposed service runs and building projections where MHE contact is a known and recurring risk. It also works well at column bases and pedestrian access points where a compact barrier is needed without the footprint of a full bollard system. Wherever the risk is real but the space is tight, this post fits.

It performs across ambient, chilled and freezer environments, making it suitable for food production facilities and cold storage sites where hygiene and material safety are additional requirements alongside physical protection. Its straightforward installation makes it a practical addition to any existing safety layout, either as a standalone measure or in combination with other barriers in the Brandsafe range.

Supporting compliance and duty of care

Under the Workplace (Health, Safety and Welfare) Regulations 1992 and the Health and Safety at Work Act 1974, employers are required to maintain safe working environments and take reasonable steps to prevent foreseeable damage to infrastructure, equipment and people. Vulnerable doors, services and building projections in areas where MHE operates represent exactly this kind of foreseeable risk.

The ImpactSAFE Protection Post provides a practical, low-cost physical control measure at the point where that risk occurs. For facilities managers and H&S managers, installing post protection at known impact points demonstrates a proactive approach to risk management and reduces the likelihood of damage or injury escalating into a more serious incident. The result is fewer near misses, incidents, and lower repair costs and a safer site overall.

Explore the Brandsafe range

The ImpactSAFE Protection Post is part of Brandsafe’s wider range of warehouse and industrial safety products. As part of IWS Group, Brandsafe supplies impact protection systems across the full site, including Armco barriers, polymer barriers, bollards and traffic management solutions. Whether you are specifying protection for doors, columns, pedestrian routes or vehicle access points, the Brandsafe team can advise on the right solution for your site.
